Sheathed thermocouples with a small connection head are suitable for measurements in various fluids. The connection head is suitable for holding a terminal block or transmitter Ø44 x 28mm for permanently connecting a connection cable.
| 16 | - | MM | XX | TT | - | DD | - | F | - | LLLL | CC |
| 16 | - | 02 | 02 | 05 | - | 015 | - | S | - | 0500 | BAW |
Straight mineral insulated thermocouple duplex type N with Inconel 600 sheath, 1.5 mm x 500 mm nominal length with connection head form B and high cover.
16-020205-60-S-0750BA, 16-020105-60-S-0530BA, 16-020105-60-S-0530BAW
You can download the free program eDrawings Viewer to view our drawing files on any device without a CAD environment.
We would be happy to accept your request. Please use the form below. You can use the search function to find the right product in our database based on article numbers, specifications or serial numbers. Alternatively, you can quickly put together your desired product using the configurator.
